1.DIAMETERS AVAILABLE: DIAMETER FROM 100MM TO 1050MM.

FOR RP GRADE, THE DIA IS USUALLY 100 -1060MM.

FOR RPI GRADE, THE DIA IS USUALLY 200 -650MM.

FOR HP GRADE, THE DIA IS USUALLY 300-650MM.

FOR SHP GRADE, THE DIA IS USUALLY FROM 400-650MM.

FOR SHP GRADE, THE DIA IS USUALLY FROM 400-650MM.



2. STANDARD GRADES – PROPERTIES: RP, RPI, HP,SHP &  UHP. (GE: ELECTRODES, GN: NIPPLES)

2.1). RP:

RESISTIVITY (UOM ): 8.0 FOR GE, 6.5 FOR GN

BENDING STRENGTH (MPA ): 9.8 FOR GE, 13 FOR GN

BULK DENSITY(G/CM3 ): 1.58 FOR GE, 1.66 FOR GN

C.T.E.(100 -600 C, 10 -6/C ): 2.9 FOR GE, 2.7 FOR GN

ASH: 0.4% FOR GE, 0.2% FOR GN

2.2). RPI:

RESISTIVITY (UOM ): 7.5 FOR GE, 6.2 FOR GN

BENDING STRENGTH (MPA ): 10.0 FOR GE, 14 FOR GN

BULK DENSITY(G/CM3 ): 1.62 FOR GE, 1.70 FOR GN

C.T.E.(100 -600 C, 10 -6/C ): 2.8 FOR GE, 2.6 FOR GN

ASH: 0.3% FOR GE, 0.2% FOR GN
