Rhenium Strip Applications
Used in coating, and thin film Chemical Vapor Deposition (CVD), and Physical Vapor Deposition (PVD) processes including Thermal, and Electron Beam (EBeam) Evaporation, Low Temperature Organic Evaporation, Atomic Layer Deposition (ALD), Organometallic, and Chemical Vapor Deposition (MOCVD). Also, there are specific applications in fuel cells and solar energy.
Rhenium Strip Specification
Material: Re>99.95%; Re>99.99%
Dimensions of Rhenium Strip
|
Dimension |
Range, mm |
|
Thickness |
0.07-1.6 |
Chemical Composition of Rhenium Strip
Re 99.99% min(Calculated by the subtraction method, excluding gas elements )
Maximum trace metallic impurities, analyzed by ICP-MS
|
Al |
1 ppm |
Mo |
10 ppm |
|
Ba |
1 ppm |
Na |
5 ppm |
|
Be |
1 ppm |
Ni |
5 ppm |
|
Ca |
5 ppm |
Pb |
1 ppm |
|
Cd |
1 ppm |
Pt |
1 ppm |
|
Co |
5 ppm |
Sb |
1 ppm |
|
Cr |
1 ppm |
Sn |
1 ppm |
|
Cu |
1 ppm |
Ti |
5 ppm |
|
K |
5 ppm |
W |
10 ppm |
|
Mg |
1 ppm |
Zn |
1 ppm |
|
Mn |
1 ppm |
|
|
