Specification |
Current rating |
Mesh Diamond (mm) |
Expected Life(Y) |
|
10mm x76m |
2.8mA/m |
2.5 x 4.6 x 0.6 |
75 |
|
13mm x76m |
3.5mA/m |
2.5 x 4.6 x 0.6 |
75 |
|
19mm x76m |
5.28mA/m |
2.5 x 4.6 x 0.6 |
75 |
|
1100mmx76m |
18.8mA/m |
34 x 76 x 0.64 |
75 |
|
1220mmx76m |
37.8mA/m |
25 x 51 x 0.89 |
75 |
|
1220mmx76m |
24.4mA/m |
34x 76 x 0.89 |
75 |
Applications
It for Cathodic Protection is designed for application in cathodic protection systems in reinforced structures, etc.
FEATURES
* Low consumption rate
* Easy installation
* Low maintain cost
* Stable and Economy
* Effective and environmental
* Long working life
